Spectral-Line Observations Using a Phased Array Feed on the Parkes Telescope

  • T.N. Reynolds (a1) (a2), L. Staveley-Smith (a1) (a2), J. Rhee (a1) (a2), T. Westmeier (a1), A. P. Chippendale (a3), X. Deng (a3) (a4), R. D. Ekers (a3) and M. Kramer (a4)...

We present first results from pilot observations using a phased array feed (PAF) mounted on the Parkes 64-m radio telescope. The observations presented here cover a frequency range from 1 150 to 1 480 MHz and are used to show the ability of PAFs to suppress standing wave problems by a factor of ~10, which afflict normal feeds. We also compare our results with previous HIPASS observations and with previous H i images of the Large Magellanic Cloud. Drift scan observations of the GAMA G23 field resulted in direct H i detections at z = 0.0043 and z = 0.0055 of HIPASS galaxies J2242-30 and J2309-30. Our new measurements generally agree with archival data in spectral shape and flux density, with small differences being due to differing beam patterns. We also detect signal in the stacked H i data of 1 094 individually undetected galaxies in the GAMA G23 field in the redshift range 0.05 ⩽ z ⩽ 0.075. Finally, we use the low standing wave ripple and wide bandwidth of the PAF to set a 3σ upper limit to any positronium recombination line emission from the Galactic Centre of <0.09 K, corresponding to a recombination rate of <3.0 × 1045 s−1.

Corresponding author
5 Email:
Hide All
Anantharamaiah, K. R., Radhakrishnan, V., Morris, D., Vivekanand, M., Downes, D., & Shukre, C. S. 1989, in IAU Symp., Vol. 136, The Center of the Galaxy, ed. M. Morris (Dordrecht: Kluwer Academic Publishers), 607
Bannister, K., & Hotan, A. 2015, Technical report, ASKAP Commissioning and Early Science Memo 004 (Epping: CSIRO Astronomy and Space Science)
Barnes, D. G., et al. 2001, MNRAS, 322, 486 10.1046/j.1365-8711.2001.04102.x 2001MNRAS.322..486B
Bennett, C. L., et al. 2013, ApJS, 208, 20 10.1088/0067-0049/208/2/20 2013ApJS..208. . .20B
Briggs, F. H., Sorar, E., Kraan-Korteweg, R. C., & van Driel, W. 1997, PASA, 14, 37 10.1071/AS97037 1997PASA. . .14. . .37B
Brown, T., Catinella, B., Cortese, L., Kilborn, V., Haynes, M. P., & Giovanelli, R. 2015, MNRAS, 452, 2479 10.1093/mnras/stv1311 2015MNRAS.452.2479B
Brüns, C., et al. 2005, A&A, 432, 45 10.1051/0004-6361:20040321 2005A&A. . .432. . .45B
Canter, K. F., Mills, A. P. Jr., & Berko, S. 1975, PhRvL, 34, 177 10.1103/PhysRevLett.34.177 1975PhRvL..34..177C
Catinella, B., Haynes, M. P., Giovanelli, R., Gardner, J. P., & Connolly, A. J. 2008, ApJ, 685, L13 10.1086/592328 2008ApJ. . .685L..13C
Chippendale, A. P., Beresford, R. J., Deng, X., Leach, M., Reynolds, J. E., Kramer, M., & Tzioumis, T. 2016, in 2016 International Conference on Electromagnetics in Advanced Applications (ICEAA) (Cairns: IEEE), 909 10.1109/ICEAA.2016.7731550
Chippendale, A. P., & Hellbourg, G. 2017, in 2017 International Conference on Electromagnetics in Advanced applications (ICEAA), accepted, arXiv:1706.042922017arXiv170604292C
Chippendale, A., & Wormnes, K. 2013, in 2013 Asia-Pacific International Symposium and Exhibition on Electromagnetic Compatibility (Melbourne: IEEE), 1
DeBoer, D. R., et al. 2009, IEEEP, 97, 1507 10.1109/JPROC.2009.2016516 2009IEEEP..97.1507D
Delhaize, J., Meyer, M. J., Staveley-Smith, L., & Boyle, B. J. 2013, MNRAS, 433, 1398 10.1093/mnras/stt810 2013MNRAS.433.1398D
Deng, X., et al. 2017, PASA, 34, e026 10.1017/pasa.2017.20 2017PASA. . .34. . .26D
Dunning, A., Bowen, M. A., Hayman, D. B., Kanapathippillai, J., Kanoniuk, H., Shaw, R. D., & Severs, S. 2016, in 2016 46th European Microwave Conference (EuMC) (London: IEEE), 156810.1109/EuMC.2016.7824657
Ellis, S. C., & Bland-Hawthorn, J. 2009, ApJ, 707, 457 10.1088/0004-637X/707/1/457 2009ApJ. . .707..457E
Fabello, S., Catinella, B., Giovanelli, R., Kauffmann, G., Haynes, M. P., Heckman, T. M., & Schiminovich, D. 2011, MNRAS, 411, 993 10.1111/j.1365-2966.2010.17742.x 2011MNRAS.411..993F
Fridman, P. A., & Baan, W. A. 2001, A&A, 378, 327 10.1051/0004-6361:20011166 2001A&A. . .378..327F
Geréb, K., Morganti, R., & Oosterloo, T. A. 2014, A&A, 569, A35 10.1051/0004-6361/201423999 2014A&A. . .569A..35G
Geréb, K., Morganti, R., Oosterloo, T. A., Hoppmann, L., & Staveley-Smith, L. 2015, A&A, 580, A43 10.1051/0004-6361/201424810 2015A&A. . .580A..43G
Hampson, G., Brown, A., Bunton, J., Neuhold, S., Chekkala, R., Bateman, T., & Tuthill, J. 2014, in 2014 XXXI URSI General Assembly and Scientific Symposium (URSI GASS) (Beijing: IEEE), 110.1109/URSIGASS.2014.6930062
Hampson, G., et al. 2012, in 2012 International Conference on Electromagnetics in Advanced Applications (ICEAA) (Cape Town: IEEE), 80710.1109/ICEAA.2012.6328742
Hart, L., & Pedlar, A. 1980, MNRAS, 193, 781 10.1093/mnras/193.4.781 1980MNRAS.193..781H
Hay, S., & O’Sullivan, J. 2008, RaSc, 43 10.1029/2007RS003798
Hellbourg, G., Weber, R., Capdessus, C., & Boonstra, A.-J. 2012, in 2012 IEEE Statistical Signal Processing Workshop (SSP) (Ann Arbor: IEEE), 9310.1109/SSP.2012.6319860
Hellbourg, G., Bannister, K., & HotarP, A. 2016, in Radio Frequency Interference (Socorro: IEEE), 37 10.1109/RFINT.2016.7833528
Hotan, A. W., et al. 2014, PASA, 31, 41 10.1017/pasa.2014.36 2014PASA. . .31. . .41H
Indermuehle, B. T., Harvey-Smith, L., Wilson, C., & Chow, K. 2016, in Radio Frequency Interference, 43
Jonas, J. L. 2009, IEEEP, 97, 1522 10.1109/JPROC.2009.2020713 2009IEEEP..97.1522J
Kesteven, M. J., & Pedlar, A. 1977, MNRAS, 180, 731 10.1093/mnras/180.4.731 1977MNRAS.180..731K
Kim, S., Staveley-Smith, L., Dopita, M. A., Sault, R. J., Freeman, K. C., Lee, Y., & Chu, Y.-H. 2003, ApJS, 148, 473 10.1086/376980 2003ApJS..148..473K
Kleiner, D., Pimbblet, K. A., Heath Jones, D., Koribalski, B. S., & Serra, P. 2016, MNRAS, 4692 10.1093/mnras/stw3328 2016MNRAS.tmp.1564K
Lah, P., et al. 2007, MNRAS, 376, 1357 10.1111/j.1365-2966.2007.11540.x 2007MNRAS.376.1357L
Leventhal, M., MacCallum, C. J., & Stang, P. D. 1978, ApJ, 225, L11 10.1086/182782 1978ApJ. . .225L..11L
McGee, R. X., & Milton, J. A. 1966, AuJPh, 19, 343 10.1071/PH660343 1966AuJPh..19..343M
Meyer, M. J., et al. 2004, MNRAS, 350, 1195 10.1111/j.1365-2966.2004.07710.x 2004MNRAS.350.1195M
Nan, R., et al. 2011, IJMPD, 20, 989 10.1142/S0218271811019335 2011IJMPD..20..989N
Oosterloo, T., Verheijen, M. A. W., van Cappellen, W., Bakker, L., Heald, G., & Ivashina, M. 2009, in Proc. of Wide Field Astronomy & Technology for the Square Kilometre Array (SKADS), held in Chateau de Limelette, 4–6 November, 702009wska.confE..70O
Oosterloo, T., Verheijen, M., & van Cappellen, W. 2010, in Proc. of the ISKAF2010 Science Meeting, held in Assen, 10–14 June, 432010iska.meetE..43O
Pen, U.-L., Staveley-Smith, L., Peterson, J. B., & Chang, T.-C. 2009, MNRAS, 394, L6 10.1111/j.1745-3933.2008.00581.x 2009MNRAS.394L. . .6P
Planck Collaboration et al., 2015, A&A, 594, A13 10.1051/0004-6361/201525830 2016A%26A. . .594A..13P
Popping, A., & Braun, R. 2008, A&A, 479, 903 10.1051/0004-6361:20079122 2008A&A. . .479..903P
Price, D. C., Barsdell, B. R., & Greenhill, L. J. 2015, A&C, 12, 212 10.1016/j.ascom.2015.05.001 2015A&C. . ..12..212P
Reynolds, J. 1994, ATNF Technical Memo, AT 39.3/040
Rhee, J., Zwaan, M. A., Briggs, F. H., Chengalur, J. N., Lah, P., Oosterloo, T., & van der Hulst, T. 2013, MNRAS, 435, 2693 10.1093/mnras/stt1481 2013MNRAS.435.2693R
Rhee, J., Lah, P., Chengalur, J. N., Briggs, F. H., & Colless, M. 2016, MNRAS, 460, 2675 10.1093/mnras/stw1097 2016MNRAS.460.2675R
Riegel, K. W., & Kilston, S. D. 1970, ApJ, 159 10.1086/180501 1970ApJ. . .159L.155R
Roberts, M. S., & Lockman, F. J. 1970, ApJ, 161, 877 10.1086/150591 1970ApJ. . .161..877R
Roshi, D. A., et al. 2015, in 2015 IEEE International Symposium on Antennas and Propagation & USNC/URSI National Radio Science Meeting (Vancouver: IEEE), 13762015isap.confE. . .2R
Ryder, S. D., Walsh, W., & Malin, D. 1999, PASA, 16, 84 10.1071/AS99084 1999PASA. . .16. . .84R
Schinckel, A. E. T., & Bock, D. C.-J. 2016, in SPIE, Vol. 9906, Ground-Based Airborne Telescopes VI, eds. Hall, H. J., Gilmozzi, R., & Marshall, H. K. (Edinburgh: SPIE), 99062A 2015isap.confE. . .2R
Serra, P., et al. 2015, MNRAS, 452, 2680 10.1093/mnras/stv1326 2015MNRAS.452.2680S
Staveley-Smith, L., et al. 1996, PASA, 13, 243 1996PASA. . .13..243S
Staveley-Smith, L., Kim, S., Calabretta, M. R., Haynes, R. F., & Kesteven, M. J. 2003, MNRAS, 339, 87 10.1046/j.1365-8711.2003.06146.x 2003MNRAS.339. . .87S
van Ardenne, A. 2010, in 2010 Joint European and National Astronomy Meeting (JENAM 2010), held in Lisbon, 6–10 September, 163
Warnick, K. F., Maaskant, R., Ivashina, M. V., Davidson, D. B., & Jeffs, B. D. 2016, IEEEP, 104, 607 10.1109/JPROC.2015.2491886
Wilson, C., Storey, M., & Tzioumis, T. 2013, in 2013 Asia-Pacific Symposium on Electromagnetic Compatibility (APEMC) (Melbourne: IEEE), 1
