SALT HRS Discovery of the Binary Nucleus of the Etched Hourglass Nebula MyCn 18

  • Brent Miszalski (a1) (a2), Rajeev Manick (a3), Joanna Mikołajewska (a4), Hans Van Winckel (a3) and Krystian Iłkiewicz (a4)...
Abstract

The shaping of various morphological features of planetary nebulae is increasingly linked to the role of binary central stars. Identifying a binary within a planetary nebula offers a powerful tool with which to directly investigate the formation mechanisms behind these features. The Etched Hourglass Nebula, MyCn 18, is the archetype for several binary-linked morphological features, yet it has no identified binary nucleus. It has the fastest jets seen in a planetary nebula of 630 km s−1, a central star position offset from the nebula centre, and a bipolar nebula with a very narrow waist. Here we report on the Southern African Large Telescope High Resolution Spectrograph detection of radial velocity variability in the nucleus of MyCn 18 with an orbital period of 18.15 ± 0.04 d and a semi-amplitude of 11.0 ± 0.3 km s−1. Adopting an orbital inclination of 38 ± 5° and a primary mass of 0.6 ± 0.1 M yields a secondary mass of 0.19 ± 0.05 M corresponding to an M5V companion. The detached nature of the binary rules out a classical nova as the origin of the jets and the offset central star as hypothesised in the literature. Furthermore, scenarios that produce the offset central star during the AGB and that form narrow waist bipolar nebulae result in orbital separations 80–800 times larger than observed in MyCn 18. The inner hourglass and jets may have formed from part of the common envelope ejecta that remained bound to the binary system in a circumbinary disk, whereas the offset central star position may best be explained by proper motion. Detailed simulations of MyCn 18 are encouraged that are compatible with the binary nucleus to further investigate its complex formation history.

Copyright
Corresponding author
5Email: brent@saao.ac.za
References
Hide All
Afşar, M., & İbanoǧlu, C. 2008, MNRAS, 391, 802
Ballester, P. 1992, Reduction of Echelle Spectra with MIDAS, in ESO Conference and Workshop Proceedings, No. 41, 4th ESO/ST-ECF Data Analysis Workshop, Held 13–14 May, 1992, eds. P.J. Grosbøl and R.C.E. de Ruijsscher, 177
Blackman, E. G., & Lucchini, S. 2014, MNRAS, 440, L16
Bond, H. E. 2000, in ASP Conf. Ser., Vol. 199, Asymmetrical Planetary Nebulae II: From Origins to Microstructures, eds. Kastner, J. H., Soker, N., & Rappaport, S., 115
Bramall, D. G., et al. 2010, Proc. SPIE, 7735, 77354F
Bramall, D. G., et al. 2012, Proc. SPIE, 8446, 84460A
Bressan, A., et al. 2012, MNRAS, 427, 127
Bryce, M., López, J. A., Holloway, A. J., & Meaburn, J. 1997, ApJL, 487, L161
Buckley, D. A. H., Swart, G. P., & Meiring, J. G. 2006, Proc. SPIE, 6267, 62670Z
Burrows, C. J., et al. 1995, ApJ, 452, 680
Chen, Y., et al. 2014, MNRAS, 444, 2525
Clark, D. M., López, J. A., Edwards, M. L., & Winge, C. 2014, AJ, 148, 98
Clyne, N., et al. 2014, A&A, 569, A50
Clyne, N., et al. 2015, A&A, 582, A60
Corradi, R. L. M., Livio, M., Balick, B., Munari, U., & Schwarz, H. E. 2001, ApJ, 553, 211
Corradi, R. L. M., & Schwarz, H. E. 1993, A&A, 268, 714
Covey, K. R., et al. 2007, AJ, 134, 2398
Crause, L. A., et al. 2014, Proc. SPIE, 9147, 91476T
Crawford, S. M., et al. 2010, Proc. SPIE, 7737, 773725
Davis, P. J., Kolb, U., & Willems, B. 2010, MNRAS, 403, 179
Dayal, A., et al. 2000, AJ, 119, 315
De Marco, O., Hillwig, T. C., & Smith, A. J. 2008, AJ, 136, 323
De Marco, O. 2009, PASP, 121, 316
Frew, D. J. 2008, PhD thesis, Macquarie University
Frew, D. J., Parker, Q. A., & Bojičić, I. S. 2016, MNRAS, 455, 1459
García-Díaz, M. T., Clark, D. M., López, J. A., Steffen, W., & Richer, M. G. 2009, ApJ, 699, 1633
García-Hernández, D. A., et al. 2016, MNRAS, 461, 542
García-Rojas, J., Peña, M., Morisset, C., Mesa-Delgado, A., & Ruiz, M. T. 2012, A&A, 538, A54
García-Segura, G., Langer, N., Różyczka, M., & Franco, J. 1999, ApJ, 517, 767
Gleizes, F., Acker, A., & Stenholm, B. 1989, A&A, 222, 237
Guerrero, M. A., & Miranda, L. F. 2012, A&A, 539, A4710.1051/0004-6361/2011179232012A%26A...539A..47G
Gvaramadze, V. V., & Menten, K. M. 2012, A&A, 541, A7
Hillwig, T. C., Bond, H. E., Afşar, M., & De Marco, O. 2010, AJ, 140, 319
Hillwig, T. C., et al. 2016, ApJ, 832, 125
Hsia, C. H., Ip, W. H., & Li, J. Z. 2006, AJ, 131, 3040
Iaconi, R., et al. 2017, MNRAS, 464, 4028
Ivanova, N., et al. 2013, A&ARv, 21, 59
Jones, D., Van Winckel, H., Aller, A., Exter, K., & De Marco, O. 2017, A&A, 600, L9
Kashi, A., & Soker, N. 2011, MNRAS, 417, 1466
Körding, E., et al. 2008, Science, 320, 1318
Körding, E. G., Knigge, C., Tzioumis, T., & Fender, R. 2011, MNRAS, 418, L129
Kniazev, A. Y., Gvaramadze, V. V., & Berdnikov, L. N. 2016, MNRAS, 459, 3068
Kurtz, M. J., & Mink, D. J. 1998, PASP, 110, 934
Kuruwita, R. L., Staff, J., & De Marco, O. 2016, MNRAS, 461, 486
Kwok, S., & Hsia, C. H. 2007, ApJ, 660, 341
Lee, T.-H., Stanghellini, L., Ferrario, L., & Wickramasinghe, D. 2007, AJ, 133, 987
Manick, R., Miszalski, B., & McBride, V. 2015, MNRAS, 448, 1789
Mayall, M. W., & Cannon, A. J. 1940, BHarO, 913, 7
Méndez, R. H., Herrero, A., & Manchado, A. 1990, A&A, 229, 152
Méndez, R. H. 1991, in IAU Symp., Vol. 145, Evolution of Stars: the Photospheric Abundance Connection, eds. Michaud, G. & Tutukov, A. V. (Dordrecht: Kluwer), 375
Miller Bertolami, M. M. 2016, A&A, 588, A25
Miszalski, B., Acker, A., Moffat, A. F. J., Parker, Q. A., & Udalski, A. 2009, A&A, 496, 813
Miszalski, B., et al. 2011a, A&A, 528, A39
Miszalski, B., et al. 2011b, A&A, 531, A158
Miszalski, B., et al. 2016, MNRAS, 456, 633
Miszalski, B., et al. 2018, MNRAS, 473, 2275
Morris, T., & Podsiadlowski, P. 2009, MNRAS, 399, 515
Mullan, D. J. 1996, in ASP Conf. Ser., Vol. 109, Cool Stars, Stellar Systems, and the Sun, eds. Pallavicini, R. & Dupree, A. K. (San Francisco: ASP), 461
Nebot Gómez-Morán, A., et al. 2011, A&A, 536, A43
Newville, M., et al. 2016, ascl soft, ascl:1606.014
Nie, J. D., Wood, P. R., & Nicholls, C. P. 2012, MNRAS, 423, 2764
O’Connor, J. A., et al. 2000, ApJ, 531, 336
O’Donoghue, D., et al. 2006, MNRAS, 372, 151
Osten, R. A., & Wolk, S. J. 2015, ApJ, 809, 79
Passy, J.-C., et al. 2012, ApJ, 744, 52
Pauldrach, A. W. A., Hoffmann, T. L., & Méndez, R. H. 2004, A&A, 419, 1111
Press, W. H., Teukolsky, S. A., Vetterling, W. T., & Flannery, B. P. 1992, Numerical Recipes in C: The Art of Scientific Computing (2nd edn; Cambridge: Cambridge University Press)
Rajpurohit, A. S., et al. 2013, A&A, 556, A15
Ricker, P. M., & Taam, R. E. 2012, ApJ, 746, 74
Sahai, R., et al. 1999, AJ, 118, 468
Sandquist, E. L., Taam, R. E., Chen, X., Bodenheimer, P., & Burkert, A. 1998, ApJ, 500, 909
Santander-García, M., et al. 2008, A&A, 485, 117
Santander-García, M., et al. 2015, Nature, 519, 63
Shara, M. M., Yaron, O., Prialnik, D., Kovetz, A., & Zurek, D. 2010, ApJ, 725, 831
Shara, M. M., et al. 2017, Nature, 548, 558
Smith, N., Bally, J., & Walawender, J. 2007, AJ, 134, 846
Soker, N., Rappaport, S., & Harpaz, A. 1998, ApJ, 496, 842
Soker, N., & Rappaport, S. 2000, ApJ, 538, 241
Soker, N., & Kashi, A. 2012, ApJ, 746, 100
Soker, N. 2017, MNRAS, 471, 4839
Sowicka, P., et al. 2017, MNRAS, 471, 3529
Stahl, O., Kaufer, A., & Tubbesing, S. 1999, in ASP Conf. Ser., Vol. 188, Optical and Infrared Spectroscopy of Circumstellar Matter, Eds. Guenther, E., Stecklum, B., & Klose, S., 331
Stanghellini, L., & Haywood, M. 2010, ApJ, 714, 1096
Sugerman, B. E. K., Crotts, A. P. S., Kunkel, W. E., Heathcote, S. R., & Lawrence, S. S. 2005, ApJS, 159, 60
Taylor, W. D., et al. 2014, MNRAS, 442, 1483
Tocknell, J., De Marco, O., & Wardle, M. 2014, MNRAS, 439, 2014
Tsamis, Y. G., Barlow, M. J., Liu, X.-W., Danziger, I. J., & Storey, P. J. 2003, MNRAS, 345, 186
Tsamis, Y. G., Barlow, M. J., Liu, X.-W., Storey, P. J., & Danziger, I. J. 2004, MNRAS, 353, 953
Van Winckel, H., et al. 2014, A&A, 563, L10
Vaytet, N. M. H., et al. 2009, MNRAS, 398, 385
Warner, B. 1995, CAS, 28
Wesson, R., et al. 2008, ApJ, 688, L21
Yaron, O., Prialnik, D., Shara, M. M., & Kovetz, A. 2005, ApJ, 623, 398
Zacharias, N., Finch, C., & Frouard, J. 2017, AJ, 153, 166
