Tidal bending of glaciers: a linear viscoelastic approach

  • Niels Reeh (a1), Erik Lintz Christensen (a2), Christoph Mayer (a3) and Ole B. Olesen (a3)
Abstract
Abstract

In theoretical treatments of tidal bending of floating glaciers, the glacier is usually modelled as an elastic beam with uniform thickness, resting on an elastic foundation. With a few exceptions, values of the elastic (Young’s) modulus E of ice derived from tidal deflection records of floating glaciers are in the range 0.9–3 GPa. It has therefore been suggested that the elastic-beam model with a single value of E ≈ 1GPa adequately describes tidal bending of glaciers. In contrast, laboratory experiments with ice give E = 9.3 GPa, i.e. 3–10 times higher than the glacier-derived values. This suggests that ice creep may have a significant influence on tidal bending of glaciers. Moreover, detailed tidal-deflection and tilt data from Nioghalvfjerdsfjorden glacier, northeast Greenland, cannot be explained by elastic-beam theory. We present a theory of tidal bending of glaciers based on linear viscoelastic-beam theory. A four-element, linear viscoelastic model for glacier ice with a reasonable choice of model parameters can explain the observed tidal flexure data. Implications of the viscoelastic response of glaciers to tidal forcing are discussed briefly.

  • View HTML
    • Send article to Kindle

      To send this article to your Kindle, first ensure no-reply@cambridge.org is added to your Approved Personal Document E-mail List under your Personal Document Settings on the Manage Your Content and Devices page of your Amazon account. Then enter the ‘name’ part of your Kindle email address below. Find out more about sending to your Kindle. Find out more about sending to your Kindle.

      Note you can select to send to either the @free.kindle.com or @kindle.com variations. ‘@free.kindle.com’ emails are free but can only be sent to your device when it is connected to wi-fi. ‘@kindle.com’ emails can be delivered even when you are not connected to wi-fi, but note that service fees apply.

      Find out more about the Kindle Personal Document Service.

      Tidal bending of glaciers: a linear viscoelastic approach
      Available formats
      ×
      Send article to Dropbox

      To send this article to your Dropbox account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your Dropbox account. Find out more about sending content to Dropbox.

      Tidal bending of glaciers: a linear viscoelastic approach
      Available formats
      ×
      Send article to Google Drive

      To send this article to your Google Drive account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your Google Drive account. Find out more about sending content to Google Drive.

      Tidal bending of glaciers: a linear viscoelastic approach
      Available formats
      ×
Copyright
References
Hide All
Bendat J. S. and Piersol A. G. 1986. Random data, analysis and measurement procedures. New York, John Wiley and Sons Inc.
Brill R. and Camp P. R. 1961. Properties of ice. SIPRE Res. Rep. 68.
Christensen E. L., Reeh N., Forsberg R., Jorgensen J. H., Skou N. and Woelders K. 2000. A low-cost glacier-mapping system. J. Glaciol., 46(154), 531–537.
Flugge W. 1967. Viscoelasticity. Waltham, MA, Blaisdell Publishing Company.
Glen J.W. 1955. The creep of polycrystalline ice. Proc. R. Soc. London, Ser. A, 228(1175), 519–538.
Hetenyi M. 1946. Beams on elastic foundations: theory with applications in the fields of civil and mechanical engineering. Ann Arbor, MI, University of Michigan Press.
Holdsworth G. 1969. Flexure of a floating ice tongue. J. Glaciol., 8(54), 385–397.
Holdsworth G. 1977. Tidal interaction with ice shelves. An n. Geophys., 33(1/2), 133–146.
Iversen C. 1972. Tidevandsfremkaldte tværsvingninger af en flydende gletschertunge. (M.Sc. thesis, Technical University of Denmark.)
Lingle C.S., Hughes T. J. and Kollmeyer R. C. 1981. Tidal flexure of Jakobshavns glacier, West Greenland. J. Geophys. Res., 86(B5), 3960–3968.
Mayer C., Reeh N., Jung-Rothenhausler F., Huybrechts P. and Oerter H. 2000. The subglacial cavity and implied dynamics under Nioghalvfjerdsfjorden glacier, NE-Greenland. Geophys. Res. Lett., 27(15), 2289–2292.
Mellor M. 1980. Mechanical properties of polycrystalline ice. In Tryde P., ed. Physics and Mechanics of Ice, IUTAM Symposium, Technical University Denmark, Copenhagen, 6–10 August 1979. Berlin, Springer-Verlag. International Union of Theoretical and Applied Mechanics, 217–265.
Morland L.W. 1996. Dynamic impact between a viscoelastic ice floe and a rigid structure. Cold Reg. Sci. Technol., 24(1), 7–28.
Paterson W. S. B. 1994. The physics of glaciers. Third edition. Oxford, etc., Elsevier.
Petrenko V. F. and Whitworth R.W. 1999. Physics of ice. Oxford, etc., Oxford University Press.
Press W. H., Flannery B. P., Teukolsky S. A. and Vetterling W.T. 1989. Numerical recipes; the art of scientific computing (Fortran version). Cambridge, Cambridge University Press.
Reeh N. Unpublished. On the application of beam theory to glacier mechanics. Lyngby, Technical University of Denmark, Institute of Hydrodynamics and Hydraulic Engineering.
Reeh N., Mayer C., Olesen O. B., Christensen E. L. and Thomsen H. H. 2000. Tidal movement of Nioghalvfjerdsfjorden glacier, northeast Greenland: observations and modelling. Ann. Glaciol., 31, 111–117.
Rignot E. 1996. Tidal motion, ice velocity and melt rate of Petermann Gletscher, Greenland, measured from radar interferometry. J. Glaciol., 42(142), 476–485.
Rignot E.J. 1998a. Fast recession of a West Antarctic glacier. Science, 281(5376), 549–551.
Rignot E. 1998b. Hinge-line migration of Petermann Gletscher, north Greenland, detected using satellite-radar interferometry. J. Glaciol., 44(148), 469–476.
Sinha N.K. 1978. Short-term rheology of polycrystalline ice. J. Glaciol., 21(85), 457–473.
Stephenson S. N. 1984. Glacier flexure and the position of grounding lines: measurements by tiltmeter on Rutford Ice Stream, Antarctica. Ann. Glaciol., 5, 165–169.
Thomsen H. H. and 6 others. 1997. The Nioghalvfjerdsfjorden glacier project, north-east Greenland: a study of ice sheet response to climate change. Geol. Greenl. Surv. Bull. 176, 95–103.
Vaughan D.G. 1994. Investigating tidal flexure on an ice shelf using kinematic GPS. Ann. Glaciol., 20, 372–376.
Vaughan D. G. 1995. Tidal flexure at ice shelf margins. J. Geophys. Res., 100(B4), 6213–6224.
