Neural activation and radial diffusivity in schizophrenia: combined fMRI and diffusion tensor imaging study

  • Kathrin Koch (a1), Gerd Wagner (a1), Claudia Schachtzabel (a1), C. Christoph Schultz (a1), Daniel Güllmar (a2), Jürgen R. Reichenbach (a2), Heinrich Sauer (a3) and Ralf G. M. Schlösser (a3)...

Abstract

Background

Schizophrenia is associated with often widespread changes in white matter structure. Most studies have investigated changes in fractional anisotropy, whereas alterations in radial or axial diffusivity have barely been investigated until now.

Aims

To investigate radial diffusivity as a potential marker of dysmyelination in direct relation to abnormalities in neural activation.

Method

Neural activation in association with decision-making under uncertainty was investigated in 19 people with schizophrenia and 20 healthy controls and linked to radial diffusivity as measured by diffusion tensor imaging.

Results

Decision-making under uncertainty was associated with a significantly decreased activation in a frontostriatocingulate network in the schizophrenia group. Structurally, they exhibited increased radial diffusivity in temporal white matter that was negatively correlated with activation in parts of the frontostriatocingulate network.

Conclusions

Present data indicate that altered diffusivity within relevant white matter networks may be closely linked to abnormal neural activation in schizophrenia.

  • View HTML
    • Send article to Kindle

      To send this article to your Kindle, first ensure no-reply@cambridge.org is added to your Approved Personal Document E-mail List under your Personal Document Settings on the Manage Your Content and Devices page of your Amazon account. Then enter the ‘name’ part of your Kindle email address below. Find out more about sending to your Kindle. Find out more about sending to your Kindle.

      Note you can select to send to either the @free.kindle.com or @kindle.com variations. ‘@free.kindle.com’ emails are free but can only be sent to your device when it is connected to wi-fi. ‘@kindle.com’ emails can be delivered even when you are not connected to wi-fi, but note that service fees apply.

      Find out more about the Kindle Personal Document Service.

      Neural activation and radial diffusivity in schizophrenia: combined fMRI and diffusion tensor imaging study
      Available formats
      ×

      Send article to Dropbox

      To send this article to your Dropbox account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Dropbox.

      Neural activation and radial diffusivity in schizophrenia: combined fMRI and diffusion tensor imaging study
      Available formats
      ×

      Send article to Google Drive

      To send this article to your Google Drive account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Google Drive.

      Neural activation and radial diffusivity in schizophrenia: combined fMRI and diffusion tensor imaging study
      Available formats
      ×

Copyright

Corresponding author

Kathrin Koch, Department of Psychiatry and Psychotherapy, Friedrich-Schiller-University Jena, Jahnstr. 3, 07740 Jena, Germany. Email: kathrin.koch@med.uni-jena.de

Footnotes

Hide All

This work was supported by the German Research Foundation (Deutsche Forschungsgemeinschaft [KO 3744/1-1 to K.K.])

Declaration of interest

None.

Footnotes

References

Hide All
1 Manoach, DS. Prefrontal cortex dysfunction during working memory performance in schizophrenia: reconciling discrepant findings. Schizophr Res 2003; 60: 285–98.
2 van Veen, V, Carter, CS. Error detection, correction, and prevention in the brain: a brief review of data and theories. Clin EEG Neurosci 2006; 37: 330–5.
3 Bora, E, Yucel, M, Pantelis, C. Theory of mind impairment: a distinct traitmarker for schizophrenia spectrum disorders and bipolar disorder? Acta Psychiatr Scand 2009; 120: 253–64.
4 Lee, KH, Brown, WH, Egleston, PN, Green, RD, Farrow, TF, Hunter, MD, et al. A functional magnetic resonance imaging study of social cognition in schizophrenia during an acute episode and after recovery. Am J Psychiatry 2006; 163: 1926–33.
5 Koch, K, Wagner, G, Nenadic, I, Schachtzabel, C, Schultz, C, Roebel, M, et al. Fronto-striatal hypoactivation during correct information retrieval in patients with schizophrenia: an fMRI study. Neuroscience 2008; 153: 5462.
6 Schlagenhauf, F, Dinges, M, Beck, A, Wustenberg, T, Friedel, E, Dembler, T, et al. Switching schizophrenia patients from typical neuroleptics to aripiprazole: effects on working memory dependent functional activation. Schizophr Res 2010; 118: 189200.
7 Kyriakopoulos, M, Bargiotas, T, Barker, GJ, Frangou, S. Diffusion tensor imaging in schizophrenia. Eur Psychiatry 2008; 23: 255–73.
8 Pomarol-Clotet, E, Canales-Rodriguez, EJ, Salvador, R, Sarro, S, Gomar, JJ, Vila, F, et al. Medial prefrontal cortex pathology in schizophrenia as revealed by convergent findings from multimodal imaging. Mol Psychiatry 2010; 15: 823–30.
9 Song, SK, Sun, SW, Ju, WK, Lin, SJ, Cross, AH, Neufeld, AH. Diffusion tensor imaging detects and differentiates axon and myelin degeneration in mouse optic nerve after retinal ischemia. Neuroimage 2003; 20: 1714–22.
10 Song, SK, Sun, SW, Ramsbottom, MJ, Chang, C, Russell, J, Cross, AH. Dysmyelination revealed through MRI as increased radial (but unchanged axial) diffusion of water. Neuroimage 2002; 17: 1429–36.
11 Goel, V, Dolan, RJ. Anatomical segregation of component processes in an inductive inference task. J Cogn Neurosci 2000; 12: 110–9.
12 Paulus, MP, Hozack, N, Zauscher, B, McDowell, JE, Frank, L, Brown, GG, et al. Prefrontal, parietal, and temporal cortex networks underlie decision-making in the presence of uncertainty. Neuroimage 2001; 13: 91100.
13 Volz, KG, Schubotz, R, von Cramon, DY. Predicting events of varying probability: uncertainty investigated by fMRI. Neuroimage 2003; 19: 271–80.
14 Koch, K, Schachtzabel, C, Wagner, G, Schikora, J, Schultz, C, Reichenbach, JR, et al. Altered activation in association with reward-related trial-and-error learning in patients with schizophrenia. Neuroimage 2010; 50: 223–32.
15 Van Snellenberg, JX, Torres, IJ, Thornton, AE. Functional neuroimaging of working memory in schizophrenia: task performance as a moderating variable. Neuropsychology 2006; 20: 497510.
16 Annett, M. The binomial distribution of right, mixed and left handedness. Q J Exp Psychol 1967; 19: 327–33.
17 American Psychiatric Association. Diagnostic and Statistical Manual of Mental Disorder (4th edn) (DSM–IV). APA, 1994.
18 First, MB, Spitzer, RL, Williams, JBW, Gibbon, M. Structured Clinical Interview for DSM–IV (SCID). APA Press, 1996.
19 Kay, SR, Fiszbein, A, Opler, LA. The positive and negative syndrome scale (PANSS) for schizophrenia. Schizophr Bull 1987; 13: 261–76.
20 Lehrl, S. Mehrfachwahl-Wortschatz-Intelligenztest MWT-B [Multiple-choice vocabulary intelligence test]. Perimed, 1989.
21 Koch, K, Schachtzabel, C, Wagner, G, Reichenbach, JR, Sauer, H, Schlösser, R. The neural correlates of reward-related trial-and-error learning: an fMRI study with a probabilistic learning task. Learn Mem 2008; 15: 728–32.
22 Brett, M, Johnsrude, IS, Owen, AM. The problem of functional localization in the human brain. Nat Rev Neurosci 2002; 3: 243–9.
23 Smith, SM, Jenkinson, M, Woolrich, MW, Beckmann, CF, Behrens, TE, Johansen-Berg, H, et al. Advances in functional and structural MR image analysis and implementation as FSL. Neuroimage 2004; 23 (suppl 1): S20819.
24 Jones, DK, Symms, MR, Cercignani, M, Howard, RJ. The effect of filter size on VBM analyses of DT-MRI data. Neuroimage 2005; 26: 546–54.
25 Moraschi, M, Hagberg, GE, Di Paola, M, Spalletta, G, Maraviglia, B, Giove, F. Smoothing that does not blur: effects of the anisotropic approach for evaluating diffusion tensor imaging data in the clinic. J Magn Reson Imaging 31: 690–7.
26 Atkins, M, Burgess, A, Bottomley, C, Riccio, M. Chlorpromazine equivalents: a consensus of opinion for both clinical and research applications. Psychiatr Bull 1997; 21: 224–6.
27 Mori, S, van Zijl, PCM, Wakana, S, Nagae-Poetscher, LM (2005) MRI Atlas of Human White Matter. Elsevier Books, 2005.
28 Ridderinkhof, KR, Ullsperger, M, Crone, EA, Nieuwenhuis, S. The role of the medial frontal cortex in cognitive control. Science 2004; 306: 443–7.
29 Heckers, S, Weiss, AP, Deckersbach, T, Goff, DC, Morecraft, RJ, Bush, G. Anterior cingulate cortex activation during cognitive interference in schizophrenia. Am J Psychiatry 2004; 161: 707–15.
30 Woods, SW. Chlorpromazine equivalent doses for the newer atypical antipsychotics. J Clin Psychiatry 2003; 64: 663–7.
31 Weiss, EM, Siedentopf, C, Golaszewski, S, Mottaghy, FM, Hofer, A, Kremser, C, et al. Brain activation patterns during a selective attention test: a functional MRI study in healthy volunteers and unmedicated patients during an acute episode of schizophrenia. Psychiatry Res 2007; 154: 3140.
32 Song, SK, Yoshino, J, Le, TQ, Lin, SJ, Sun, SW, Cross, AH, et al. Demyelination increases radial diffusivity in corpus callosum of mouse brain. Neuroimage 2005; 26: 132–40.
33 Wheeler-Kingshott, CA, Cercignani, M. About “axial” and “radial” diffusivities. Magn Reson Med 2009; 61: 1255–60.
34 Seal, ML, Yucel, M, Fornito, A, Wood, SJ, Harrison, BJ, Walterfang, M, et al. Abnormal white matter microstructure in schizophrenia: a voxelwise analysis of axial and radial diffusivity. Schizophr Res 2008; 101: 106–10.
35 McDonald, C, Bullmore, E, Sham, P, Chitnis, X, Suckling, J, MacCabe, J, et al. Regional volume deviations of brain structure in schizophrenia and psychotic bipolar disorder: computational morphometry study. Br J Psychiatry 2005; 186: 369–77.
36 Price, G, Cercignani, M, Bagary, MS, Barnes, TR, Barker, GJ, Joyce, EM, et al. A volumetric MRI and magnetization transfer imaging follow-up study of patients with first-episode schizophrenia. Schizophr Res 2006; 87: 100–8.
37 Whitford, TJ, Grieve, SM, Farrow, TF, Gomes, L, Brennan, J, Harris, AW, et al. Volumetric white matter abnormalities in first-episode schizophrenia: a longitudinal, tensor-based morphometry study. Am J Psychiatry 2007; 164: 1082–9.
38 Ellison-Wright, I, Bullmore, E. Meta-analysis of diffusion tensor imaging studies in schizophrenia. Schizophr Res 2009; 108: 310.
39 Stephan, KE, Baldeweg, T, Friston, KJ. Synaptic plasticity and dysconnection in schizophrenia. Biol Psychiatry 2006; 59: 929–39.
40 Herwig, U, Abler, B, Walter, H, Erk, S. Expecting unpleasant stimuli – an fMRI study. Psychiatry Res 2007; 154: 112.
41 Singer, T, Critchley, HD, Preuschoff, K. A common role of insula in feelings, empathy and uncertainty. Trends Cogn Sci 2009; 13: 334–40.
42 Michailov, GV, Sereda, MW, Brinkmann, BG, Fischer, TM, Haug, B, Birchmeier, C, et al. Axonal neuregulin-1 regulates myelin sheath thickness. Science 2004; 304: 700–3.
43 Draganski, B, Moser, T, Lummel, N, Ganssbauer, S, Bogdahn, U, Haas, F, et al. Decrease of thalamic gray matter following limb amputation. Neuroimage 2006; 31: 951–7.
