‘Shear thickening’ in non-shear flows: the effect of microstructure

  • Helen J. Wilson (a1)
Abstract

The bizarre behaviour of a cornstarch suspension (sometimes called oobleck) is well known to all of us who have led public engagement events. At the right solids fraction, it flows smoothly at slow speeds, but can be shattered with a quick spoon movement; if you prepare a large enough sample, you can run across the surface (but if you stand still, you will sink). In rheology circles this phenomenon is known as shear thickening, though the flows described above are not necessarily shear-dominated. In recent years there has been a proliferation of research on the mechanism behind true shear thickening, using both experiments and numerical simulations of shear flows. The understanding of the underlying mechanism is improving markedly. But the paper ‘Microstructure and thickening of dense suspensions under extensional and shear flows’ (Seto, Giusteri & Martinello, J. Fluid Mech., vol. 825, 2017, R3) is the first to consider more general flows. We have, for the first time, simulations of thickening in extensional flows, which are a far better description of oobleck with a runner on top – and can begin to quantify the difference between the idealised shear thickening and the extension thickening that happens in practice.

  • View HTML
    • Send article to Kindle

      To send this article to your Kindle, first ensure no-reply@cambridge.org is added to your Approved Personal Document E-mail List under your Personal Document Settings on the Manage Your Content and Devices page of your Amazon account. Then enter the ‘name’ part of your Kindle email address below. Find out more about sending to your Kindle. Find out more about sending to your Kindle.

      Note you can select to send to either the @free.kindle.com or @kindle.com variations. ‘@free.kindle.com’ emails are free but can only be sent to your device when it is connected to wi-fi. ‘@kindle.com’ emails can be delivered even when you are not connected to wi-fi, but note that service fees apply.

      Find out more about the Kindle Personal Document Service.

      ‘Shear thickening’ in non-shear flows: the effect of microstructure
      Available formats
      ×
      Send article to Dropbox

      To send this article to your Dropbox account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Dropbox.

      ‘Shear thickening’ in non-shear flows: the effect of microstructure
      Available formats
      ×
      Send article to Google Drive

      To send this article to your Google Drive account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Google Drive.

      ‘Shear thickening’ in non-shear flows: the effect of microstructure
      Available formats
      ×
Copyright
Corresponding author
Email address for correspondence: helen.wilson@ucl.ac.uk
References
Hide All
Batchelor, G. K. & Green, J. T. 1972 The determination of the bulk stress in a suspension of spherical particles to order c 2 . J. Fluid Mech. 56 (2), 401427.
Brady, J. F. & Morris, J. F. 1997 Microstructure of strongly sheared suspensions and its impact on rheology and diffusion. J. Fluid Mech. 348, 103139.
Clavaud, C., Bérut, A., Metzger, B. & Forterre, Y. 2017 Revealing the frictional transition in shear-thickening suspensions. Proc. Natl Acad. Sci. 114 (20), 51475152.
Einstein, A. 1906 Eine neue Bestimmung der Moleküldimensionen. Ann. Physik 324 (2), 289306.
Fernandez, N., Mani, R., Rinaldi, D., Kadau, D., Mosquet, M., Lombois-Burger, H., Cayer-Barrioz, J., Herrman, H. J., Spencer, N. D. & Isa, L. 2013 Microscopic mechanism for shear thickening of non-Brownian suspensions. Phys. Rev. Lett. 111, 108301.
Giusteri, G. G. & Seto, R.2017 A theoretical framework for steady-state rheometry in generic flow conditions. J. Rheol. arXiv:1702.02745 (submitted).
Heussinger, C. 2013 Shear thickening in granular suspensions: interparticle friction and dynamically correlated clusters. Phys. Rev. E 88, 050201.
Lin, N. Y. C., Guy, B. M., Hermes, M., Ness, C., Sun, J., Poon, W. C. K. & Cohen, I. 2015 Hydrodynamic and contact contributions to continuous shear thickening in colloidal suspensions. Phys. Rev. Lett. 115, 228304.
Mari, R., Seto, R., Morris, J. F. & Denn, M. M. 2014 Shear thickening, frictionless and frictional rheologies in non-Brownian suspensions. J. Rheol. 58, 16931724.
Phillips, R. J., Armstrong, R. C., Brown, R. A., Graham, A. L. & Abbott, J. R. 1992 A constitutive equation for concentrated suspensions that accounts for shear-induced particle migration. Phys. Fluids 4, 3040.
Seto, R., Giusteri, G. G. & Martiniello, A. 2017 Microstructure and thickening of dense suspensions under extensional and shear flows. J. Fluid Mech. 825, R3.
Seto, R., Mari, R., Morris, J. F. & Denn, M. M. 2013 Discontinuous shear thickening of frictional hard-sphere suspensions. Phys. Rev. Lett. 111 (21), 218301.
Wyart, M. & Cates, M. E. 2014 Discontinuous shear thickening without inertia in dense non-Brownian suspensions. Phys. Rev. Lett. 112 (9), 098302.
